Weld Yourself Headache Rack Tutorial

How do our Products Work?

Watch our about video below!

Headache Rack Video Tutorial

That’s right, you can watch the whole thing, for free, before you buy. Swipe between modules, click to watch.

Shop Headache Rack Kits

Free Shipping in the lower 48 states.

Frequently Asked Questions



Standard Kit – $109  -OR-  Digital Kit – $59

*Steel you will need to purchase – $90-$110

*Finish (Paint/Powder Coat) – $10 – $150

LED Cab Lights – $17

Standard Kit Total: $226 – $386  -OR-  Digital Kit total: $176-$336

Add Marker Lights & wiring (6): +$35

Add Strip Tail/Stop/Turn Lights & wiring: +$35

Compare to Protech Premade Rack: MSRP $475-$750

Compare to Highway Products Premade Rack: MSRP $599+

*Price subject to your area’s steel retailer and powder coat supplier*

This kit gives you everything you need to seamlessly complete the base model rack. It is designed to be a cheap alternative to pre-made headache racks.

We sell two different kit options: standard and digital. Standard Kits include the CNC machine made parts shipped to your door and a model specific blueprint that lays out all of the other steel you need to purchase locally and at what lengths and angles to cut it. The digital kit is for those who own or have access to a CNC table or laser and includes the .dxf cut files for all the machine made parts in addition to a model specific blueprint. This kit is designed to be used in combination with the video tutorial.

Equipment Required:

  • Standard Protective Equipment (Ear Plugs, Safety glasses, Welding Helmet, Welding Gloves, Welding Coat)
  • Work Table
  • Welder – capable of welding 3/16” plate
  • Bandsaw capable of cutting 2.5” square tubing (If you don’t have a bandsaw, you can get your pieces cut at a local welding shop)
  • Angle Grinder
  • Tape Measure
  • Vice grips OR C-clamps – at least two, four preferred
  • Square
  • Hand Drill OR Drill Press
  • ¼” Drill Bit
  • ¾” Drill Bit (only needed if adding marker lights)
  • Type 27 Flapper Disk Grinding Wheels
  • Grinder Cutting Wheel OR Plasma Cutter OR Cutting Torch

Experienced Required:

  • Beginning to Intermediate Welding Experience
  • General Knowledge of using a bandsaw (includes cutting angles) If you don’t have a bandsaw, you can get all your pieces cut at a local welding shop.
  • General Shop Tool Knowledge (how to use hand drill, grinder, etc.)

No Experience or Tools? No Problem. Give your local welding shop a copy of the blueprint and video access and they will easily be able to complete the project.

An experienced fabricator can get this project done in 6 hours, whereas a beginner might need a full day.

Yes, this product is designed to accommodate most cross body toolboxes. Shop kits for your model for exact tolerances based on model.

Want 10% Off ANY Product?

Enter your email below. By submitting, you agree to our privacy policy.

View Product Gallery

All Variations of product shown below are buildable for multiple models using our weld yourself kits and add-ons.

PURCHASE 3RD PARTY PARTS BELOW

Red Parts are needed if you choose to add LED work lights or marker lights. Blue parts are recommended Click the photo to purchase.
